M11
Category:
Engines for power generation
keyword: dynamo,motor
Products Details
| M11 | |
| version | Inline/six-cylinder/four-stroke/four-valve |
| Bore X-stroke(mm) | 125X147mm |
| Displacement (l) | 11L |
| Air intake mode | Pressurized intercooled |
| Maximum power (hp/kW) | 418HP/312KW |
| Fuel system | CELECT Electronically controlled fuel system |
| emission | EU STGIIA |
| Dry weight (kg) | 940kg |
| Length X Width X Height (mm) | 1324X835X1183mm |
Product Advantages:
Good durability
The cylinder block and cylinder head adopt high-strength integrated design, which reduces the failure rate, is durable, and has an excellent reputation.
Excellent performance
The advanced exhaust gas turbocharger ensures that the engine has sufficient air intake, sufficient combustion and high efficiency. The pressure-type pulse exhaust pipe makes full use of waste energy and improves the low-load efficiency of the engine.
The use of CELECT electronically controlled fuel system greatly improves power and increases response speed.
High reliability
Block integration, compact structure, low failure rate, low vibration and low noise. The engine maintains optimal performance at different altitudes and load conditions.
Easy to maintain
INSITE?, a Windows-based engine monitoring and diagnostic software, provides users with a user-friendly interface and a great deal of freedom to quickly diagnose engine faults.
The overall modular design, block integration, compact structure, detachable parts, high reusability. The same platform design, high universality of parts.
The overall design of six cylinders and one cover, integrated into blocks, compact structure, detachable parts, and high reusability.
Adaptable
The oil has a wide range of adaptability and strong environmental adaptability.
